Called VPX7600, its octa-core processor supports up to 32Gbyte dual-channel soldered-down DDR4 ECC memory with data rates of up to 3.2Gtransfer/s.
An Intel Gen12 UHD Xe 32EU graphics engine can clock up to 1.35GHz, and its Intel E810 Ethernet controller works with 100Gbit/s on the data plane and 10Gbit/s on the control plane.
“Backplane IO includes DisplayPort, USB 3.2, SATA III, RS232/422 and GPIO,” according to the company, while “an NVMe SSD provides up to 1Tbyte of M.2 data storage” – 64Gbyte is standard.
Conduction-cooled and air-cooled with front IO versions are available.
Defence, aerospace and scientific applications are expected.
Find the Acromag VPX7600 web page here
Last month, Abaco Systems announced a SOSA-aligned Open VPX 3U video graphics and GPGPU card.
